Weber 32/36 Carburetor Only 20R/22R Electric Choke
Weber 32/36 Carburetor Only 20R/22R Electric Choke

Our Price: $301.99

Quantity in Stock:(Backordered)

Part Number: 1030031
Qty:

Details Fitment Instructions


Weber 32/36 Carburetor Only

(Electric Choke)

Weber 32/36 Carburetor Only

The Weber 32/36 carb only utilizes a 32/36 progressive Weber carb and is designed to upgrade your Toyota with an economical performance carb. Increase horsepower as well as improve drivability and fuel economy compared the stock carburetor. The Weber 32/36 is the optimum carburetor to replace a worn out or hard to maintain factory carb. The 32/36 progressive is an excellent carb for low-end power and fuel economy. If you've got a mildly built motor or daily driver, the 32/36 is the way to go for torque, low-end power, and fuel economy. This is an electric choke carb. This is only the carb no air filter and no adapter plate. This is perfect for someone that is replacing a Weber or is running our spiral adapter and K&N air cleaner or our billet air cleaner.

For over 20 years we have been selling the Weber carb kits for the Toyota's with great success. Unless you are replacing a Weber that was already installed, we recommend going with the whole carb kit. This carb only kit is just that, the carburetor only. To install the following may be required instructions, gaskets for mounting, air cleaner, linkage parts, and fuel regulator.


NOTE:
This may need to have the jets replaced to work properly with your application, see Part #: 1035002. All those parts are available separately and are not included.


NOTE: Requires 2.5 - 3 lbs of fuel pressure, see regulator kit Part #: 1035056. This carburetor does not come with provisions to run a kick-down cable for an automatic transmission. If your Kick Down cable attaches to the Bell Crank, you will not be affected. If it attaches to the carb, modifications will be needed. Most are to the Bell Crank from the factory. Factory fuel line from the mechanical pump is roughly 1/16" smaller than Weber Regulator/Carb fuel line. Slight pressure is all that is needed to fit the smaller line

Weber carb adapter plates have been known to leak, therefore LC Engineering came up with a design that not only seals perfectly, but improves horsepower, due to its spiral cut design, allowing for better air / fuel atomization.

  • LC Engineering Pro Spiral Spacer - 1" Weber Carb. Spacer kit, see Part #: 1033023
  • LC Engineering Spiral Adapter - Weber to 22R Stock Manifold, see Part #: 1033028
  • LC Engineering Spiral Adapter - Stock 22R Carb. to Weber Flange, see Part #: 1033060

Related Weber 32/36 Kits:

  • Weber 32/36 Carburetor Only 20R/22R Manual Choke, see Part #: 1030035
  • Weber 32/36 Carburetor Kit With Electric Choke - 20R/22R, see Part #: 1030021
  • Weber 32/36 Carburetor Kit With Manual Choke 20R/22R, see Part #: 1030032
  • 22R Weber 32/36 Carburetor Kit 81-83 (Smog Legal) 2WD Pickup & Celica, see Part #: 1030062
  • 22R Weber 32/36 Carburetor Kit 81-84 (Smog Legal) 4WD Pickup, see Part #: 1030063
  • Weber 32/36 Carburetor Performance Package With Electric Choke, see Part #: 1030026
  • Weber 32/36 Carburetor Performance Package With Manual Choke, see Part #: 1030028
  • Weber 32/36 Carb Kit w/K&N & Billet Cleaner-20R/22R, see Part #: 1030024
  • Weber 32/36 Carb Kit w/K&N Filter (11" x 2")-20R/22R, see Part #: 1030018
  • Weber 32/36 Carb & Intake Performance Package 22R with Stock Weber Air Cleaner, see Part #: 1030066
  • Weber 32/36 Carb & Intake Performance Package Toyota 20R (Manual Choke), see Part #: 1030000
  • Weber 32/36 Carb & Intake Performance Package 20R (Electric Choke), see Part #: 1030003
  • Weber 32/36 Carb & Intake Performance Package 22R, see Part #: 1030039
  • Weber 32/36 Carb & Intake Performance Package 22R, see Part #: 1030036


Contact our Tech Support Line for further information at 928-575-2174.

Note: Images are for illustration purposes only. Images may not represent the product listed. Please contact customer service with any questions or concerns: 1-928-505-2501.
